AUO C129HAX02.0 LCD

Specification

Model P/N:C129HAX02.0
Brand:AUO
Diagonal Size:12.9"
Resolution:1920(RGB)×1080, FHD 171PPI
Contrast Ratio:1200:1 (Min.) (TM)
Viewing Angle:-
Panel Type:LTPS TFT-LCD, CELL , FOG
Pixel Format:RGB Vertical Stripe
Active Area:285.12(W)×160.38(H) mm
Bezel Opening:-
Outline Dim:289.12(H)×169.68(V) ×0.77(D) mm
Treatment:Antiglare, Hard coating
Luminance:0 cd/m²
View Direction:Symmetry
Response Time:20 (Max.)(Tr+Td)
Operating Mode:AHVA, Normally Black, Transmissive
Support Color:16.7M 86% NTSC
Light Source:No B/L
Weight:-
Designed For:Automotive Display
Frame Rate:60Hz
Touch Panel:In-Cell Touch, I²C
Interface Type:LVDS (2 ch, 8-bit) , 120 pins FPC
Plate Thickness:0.25+0.25 mm
Transmittance:4.76% (Typ.)(with Polarizer)
D-IC Detail:COG Built-in HX83193-B
