AUO C127UAC01.0 LCD

Specification

Model P/N:C127UAC01.0
Brand:AUO
Diagonal Size:12.7"
Resolution:2240×182(RGB) 177PPI
Contrast Ratio:1100 : 1 (Min.) (TM)
Viewing Angle:80/80/80/80 (Min.)(CR≥10)
Color Depth:16.7M 100% sRGB
Backlight:10S3P WLED , 10K hours , No Driver
Signal Type:LVDS (2 ch, 8-bit) , Connector 160 pins
Panel Type:a-Si TFT-LCD, LCM
Pixel Format:RGB Horizontal Stripe
Active Area:320.544(W)×26.0442(H) mm
Bezel Opening:-
Treatment:-
Luminance:800 cd/m² (Min.)
Response:20 (Max.)(G to G) ms
Good View at:Symmetry
Work Mode:AHVA, Normally Black, Transmissive
Mass:182g (Typ.)
Used for:Outdoor High Brightness ，Automotive Display
Refresh Rate:60Hz
Touchscreen:Without
Voltage Supply:3.3/6.5/6.5V (Typ.)(VCC/VSP/VSN)
Max Ratings:Storage Temp.: -55 ~ 125 °C Operating Temp.: -40 ~ 105 °C ; Vibration Level: 2.9G (28.4 m/s²)
Outline (mm):339.54×49.84 (H×V×D)
