BOE BV050WVM-N00 LCD

Specification

Model P/N:BV050WVM-N00
Brand:BOE
Diagonal Size:5.0"
Resolution:480(RGB)×800, WVGA 186PPI
Brightness:435 cd/m² (Typ.)
Contrast Ratio:900:1 (Typ.) (TM)
Viewing Angle:85/85/85/85 (Typ.)(CR≥10)
Panel Type:a-Si TFT-LCD, LCM
Pixel Format:RGB Vertical Stripe
Active Area:65.52(W)×109.2(H) mm
Bezel Opening:-
Response Time:30 (Typ.)(Tr+Td)
Outline Size:70.12(W)×118.98(H) ×1.9(D) mm
Surface:Hard coating (3H), Antireflection
Best View on:Symmetry
Display Colors:16.7M 51% NTSC
Lamp Type:5S2P WLED , Without Driver
Panel Weight:35.0±3.5g
Application:Mobile Phone
Signal Interface:MIPI (4 data lanes) , 30 pins Connector
Input Voltage:1.8/3.3V (Typ.)(IOVCC/VCI)
