BOE BTL404880-W557LP LCD

Specification

Model P/N:BTL404880-W557LP
Brand:BOE
Diagonal Size:4.0"
Resolution:480(RGB)×800, WVGA 235PPI
Brightness:350 cd/m² (Typ.)
Contrast Ratio:700:1 (Typ.) (TM)
Viewing Angle:85/85/85/85 (Typ.)(CR≥10)
Panel Type:a-Si TFT-LCD, LCM
Pixel Format:RGB Vertical Stripe
Active Area:51.84(W)×86.4(H) mm
Bezel Opening:-
Response Time:35 (Typ.)(Tr+Td)
Outline Size:57.08(W)×98.2(H) ×1.95(D) mm
Surface:Clear
Best View on:Symmetry
Display Colors:16.7M 71% NTSC
Lamp Type:8S1P WLED , Without Driver
Frequency:60Hz
Touch Screen:Without
Panel Weight:TBD
Application:Mobile Phone
Signal Interface:MDDI/MIPI , 25 pins FPC
Input Voltage:1.8/2.8V (Typ.)(IOVCC/VCI)
