AUO B154PW02 V1 LCD

Specification

Model P/N:B154PW02 V1
Brand:AUO
Diagonal Size:15.4"
Resolution:1440(RGB)×900, WXGA+ 110PPI
Contrast Ratio:400:1 (Typ.) (TM)
Viewing Angle:70/70/60/60 (Typ.)(CR≥10)
Panel Type:a-Si TFT-LCD, LCM
Pixel Format:RGB Vertical Stripe
Active Area:331.56(W)×207.225(H) mm
Bezel Opening:335.36(W)×211.06(H) mm
Outline Dim:344(H)×222(V) ×6.1(D) mm
Treatment:Glare (Haze 0%), Hard coating (3H)
Luminance:250 cd/m² (Typ.)
View Direction:-
Response Time:4/12 (Typ.)(Tr/Td)
Operating Mode:TN, Normally White, Transmissive
Support Color:262K 46% NTSC
Light Source:CCFL [1 pcs] , W/O Driver
Designed For:Laptop
Frame Rate:60Hz
Touch Panel:Without
Interface Type:LVDS (2 ch, 6-bit) , 30 pins Connector
Power Supply:3.3V (Typ.)
Form Style:Wedge (PCBA Bent, T≥5.2mm)
