OPTREX T-51638D084-FW-A-AA LCD

Specification

Model P/N:T-51638D084-FW-A-AA
Brand:OPTREX
Diagonal Size:8.4"
Resolution:640(RGB)×480, VGA 95PPI
Brightness:450 cd/m² (Typ.)
Contrast Ratio:450:1 (Typ.) (TM)
Viewing Angle:65/65/50/60 (Typ.)(CR≥10)
Panel Type:a-Si TFT-LCD, LCM
Pixel Format:RGB Vertical Stripe
Active Area:170.88(W)×128.16(H) mm
Bezel Opening:174.9(W)×132.2(H) mm
Response Time:8/27 (Typ.)(Tr/Td)
Outline Size:199.5(W)×149(H) ×12(D) mm
Surface:Antiglare, Hard coating (3H)
Best View on:6 o'clock
Display Colors:262K 39% NTSC
Lamp Type:2 pcs CCFL , 50K hours , Without Driver
Frequency:60Hz
Touch Screen:Without
Panel Weight:360g (Typ.)
Application:Industrial
Signal Interface:CMOS (1 ch, 6-bit) , 31 pins Connector
Input Voltage:3.3V (Typ.)
