AUO A090VW01 V0 LCD

Specification

Model P/N:A090VW01 V0
Brand:AUO
Diagonal Size:9.0"
Resolution:800×480(RGB), WVGA 104PPI
Contrast Ratio:500:1 (Typ.) (TM)
Viewing Angle:70/70/55/70 (Typ.)(CR≥10)
Panel Type:a-Si TFT-LCD, LCM
Pixel Format:RGB Horizontal Stripe
Active Area:199.2(W)×110.16(H) mm
Bezel Opening:201.2(W)×112.16(H) mm
Outline Dim:211.7(H)×125(V) ×5(D) mm
Treatment:Antiglare, Hard coating (3H)
Luminance:250 cd/m² (Typ.)
View Direction:6 o'clock
Response Time:4/12 (Typ.)(Tr/Td)
Operating Mode:TN, Normally White, Transmissive
Support Color:16.7M 48% NTSC
Light Source:WLED [3S8P] , 10K hours , W/O Driver
Weight:220g (Typ.)
Designed For:Digital Photo Frame ，Portable DVD Player
Frame Rate:60Hz
Touch Panel:Without
Interface Type:TTL (1 ch, 8-bit) + SPI , 68 pins FPC
Power Supply:3.3/5.5/-5.5/10/-13V (Typ.)(VCC/VDPA/VDNA/VGH/VGL)
