CSOT MNG007DA1-1 LCD

Specification

Model P/N:MNG007DA1-1
Brand:CSOT
Diagonal Size:16.0"
Resolution:2560(RGB)×1600, WQXGA 188PPI
Contrast Ratio:1200 : 1 (Typ.) (TM)
Viewing Angle:89/89/89/89 (Typ.)(CR≥10)
Color Depth:1.07B 100% sRGB
Backlight:12S6P WLED , 15K hours , With LED Driver
Signal Type:eDP (4 Lanes) , eDP1.4 , Connector 40 pins
Panel Type:LTPS TFT-LCD, LCM
Pixel Format:RGB Vertical Stripe
Active Area:344.678(W)×215.424(H) mm
Bezel Opening:-
Treatment:Antiglare, Hard coating (3H), Reflection 6.5% (Max.)
Luminance:500 cd/m² (Typ.)
Response:9 (Typ.)(Tr+Td), 3 (Typ.)(G to G)(OD) ms
Good View at:Symmetry
Work Mode:FFS, Normally Black, Transmissive
Used for:Laptop
Refresh Rate:165Hz
Touchscreen:Without
Voltage Supply:3.3V (Typ.)
Max Ratings:Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C
Outline (mm):349.68×224.42×4.6 (H×V×D)
Outline Shape:Slim (PCBA Bent, T≤3.0mm)
