Samsung AMS465GS45 LCD

Specification

Model P/N:AMS465GS45
Brand:Samsung
Diagonal Size:4.7"
Resolution:720(RG/BG)×1280, WXGA 257PPI
Contrast Ratio:3400:1 (Min.) (TM)
Viewing Angle:80/80/80/80 (Min.)(CR≥10)
Panel Type:AM-OLED, Assembly
Pixel Format:RG/BG PenTile
Active Area:57.96(W)×103.04(H) mm
Bezel Opening:-
Outline Dim:65.2(H)×131.1(V) mm
Treatment:Hard coating
Luminance:300 cd/m² (Typ.)
View Direction:Symmetry
Response Time:2 (Max.)
Operating Mode:-
Support Color:16.7M 106% NTSC
Light Source:self
Weight:-
Designed For:Mobile Phone
Frame Rate:60Hz
Touch Panel:PCAP, I²C
Interface Type:MIPI (4 data lanes) , 44 pins Connector
Power Supply:2.2/3.1/3.3V (Typ.)(VDD3/VCI/VBAT)
