LG Display LM195WD1-TJBA LCD

Specification

Model P/N:LM195WD1-TJBA
Brand:LG Display
Diagonal Size:19.5"
Resolution:1600(RGB)×900, HD+ 94PPI
Brightness:0 cd/m²
Contrast Ratio:600:1 (Typ.) (TM)
Viewing Angle:45/45/15/35 (Typ.)(CR≥10)
Panel Type:a-Si TFT-LCD, CELL , FOB
Pixel Format:RGB Vertical Stripe
Active Area:433.92(W)×236.34(H) mm
Bezel Opening:-
Response Time:1.3/3.7 (Typ.)(Tr/Td)
Outline Size:444.92(W)×244.74(H) ×1.43(D) mm
Surface:Antiglare, Hard coating (3H)
Best View on:6 o'clock
Display Colors:16.7M 72% NTSC
Lamp Type:No B/L , Without Driver
Frequency:75Hz
Touch Screen:Without
Panel Weight:343g (Typ.)
Application:Desktop Monitor
Signal Interface:LVDS (2 ch, 8-bit) , 30 pins Connector
Input Voltage:5.0V (Typ.)
Driver IC:COFBuilt-in 5 source chips
Glass Depth:0.50+0.50 mm
Transmissivity:5.11% (Typ.)(with Polarizer)
