BOE NE156FHM-NZ3 V8.0 LCD

Specification

Model P/N:NE156FHM-NZ3 V8.0
Brand:BOE
Diagonal Size:15.6"
Resolution:1920(RGB)×1080, FHD 141PPI
Contrast Ratio:1000 : 1 (Typ.) (TM)
Viewing Angle:85/85/85/85 (Typ.)(CR≥10)
Color Depth:16.7M 100% sRGB
Backlight:11S4P WLED , 15K hours , With LED Driver
Signal Type:eDP (4 Lanes) , eDP1.4 , HBR3 (8.1G/lane) , Connector 40 pins
Panel Type:Oxide TFT-LCD, LCM
Pixel Format:RGB Vertical Stripe
Active Area:344.16(W)×193.59(H) mm
Bezel Opening:-
Treatment:Antiglare, Hard coating (3H)
Luminance:300 cd/m² (Typ.)
Response:9 (Typ.)(Tr+Td), 5 (Typ.)(G to G), 2 (Typ.)(G to G)(OD) ms
Good View at:Symmetry
Work Mode:HADS, Normally Black, Transmissive
Used for:Laptop ，Gaming
Refresh Rate:360Hz
Touchscreen:Without
Voltage Supply:3.3V (Typ.)
Max Ratings:Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C
Outline (mm):350.66×216.05×2.6 (H×V×D)
Outline Shape:Slim (PCBA Flat, T≤3.2mm)
