NEC NL128102AC28-07 LCD

Specification

Model P/N:NL128102AC28-07
Brand:NEC
Diagonal Size:18.1"
Resolution:1280(RGB)×1024, SXGA 90PPI
Contrast Ratio:300 : 1 (Typ.) (TM)
Viewing Angle:85/85/85/85 (Typ.)(CR≥10)
Color Depth:16.7M 60% NTSC
Backlight:12 pcs CCFL , With Inverter
Signal Type:LVDS (2 ch, 8-bit) , 50 pins Connector
Panel Type:a-Si TFT-LCD, LCM
Pixel Format:RGB Vertical Stripe
Active Area:359.04(W)×287.232(H) mm
Bezel Opening:364.0(W)×292.2(H) mm
Treatment:Hard coating (2H), Antireflection
Luminance:240 cd/m² (Typ.)
Outline(mm):389 × 317.2 × 31.3 (H×V×D)
Response:15/14 (Typ.)(Tr+Td) ms
Good View at:Symmetry
Work Mode:A-SFT, Normally Black, Transmissive
Mass:1.65/1.75Kgs (Typ./Max.)
Used for:Desktop Monitor ，Industrial
Refresh Rate:60Hz
Touchscreen:Without
Voltage Supply:12.0V (Typ.)
Max Ratings:Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 55 °C
