| Model: | B170UW01 V0 |
| Brand: | AUO |
| EDID Code: | AUO1088 |
| Diagonal Size: | 17 inch |
| Resolution: | 1920 × 1200 (WUXGA) |
| Pixel Format: | RGB Vertical Stripe |
| Panel Type: | a-Si TFT-LCD, LCM |
| Display Mode: | TN, Normally White, Transmissive |
| Brightness: | 260 cd/m² (Typ.) |
| Contrast Ratio: | 600:1 (Typ.) (TM) |
| Viewing Angle: | 70/70/60/60 (Typ.)(CR≥10) (L/R/U/D) |
| Response Time: | 8 (Typ.)(Tr+Td) ms |
| Display Colors: | 262K 45%(CIE1931) |
| Surface: | Glare (Haze 0%), Hard coating (4H) |
| Backlight: | 1 pcs CCFL, No Driver |
| Refresh Rate: | 60 Hz |
| Interface: | LVDS (2 ch, 6-bit), Connector, 30 pins |
| Touch Panel: | Without |
| Active Area: | 367.2 × 229.5 mm |
| Bezel Opening: | 371.2 × 233.5 mm |
| Outline Dimensions: | 382.2 × 243.3 × 6.6 mm |
| Shape: | Wedge (PCBA Bent, Depth ≥5.2mm) |
| Power Supply: | 3.3V (Typ.) |
| Operating Temperature: | 0 ~ 50 °C |
| Storage Temperature: | -20 ~ 60 °C |
| Application: | Laptop |
The same device model may use different screens. Please check the part number on the back of your original screen before ordering.
