| Model: | DV170YGM-N10 |
| Brand: | BOE |
| Diagonal Size: | 17 inch |
| Resolution: | 1280 × 960 (Quad-VGA, 94 PPI) |
| Pixel Format: | RGB Vertical Stripe |
| Panel Type: | a-Si TFT-LCD, LCM |
| Display Mode: | ADS, Normally Black, Transmissive |
| Brightness: | 250 cd/m² (Typ.) |
| Contrast Ratio: | 1000:1 (Typ.) (TM) |
| Viewing Angle: | 89/89/89/89 (Typ.)(CR≥10) (L/R/U/D) |
| Best Viewing Direction: | Symmetry |
| Response Time: | 14 (Typ.)(G to G) ms |
| Display Colors: | 16.7M 99% sRGB |
| Surface: | Antiglare (Haze 25%), Hard coating (3H) |
| Backlight: | WLED [4 strings], 30K hours, W/O Driver |
| Refresh Rate: | 60 Hz |
| Interface: | LVDS (2 ch, 8-bit), 30 pins Connector |
| Touch Panel: | Without |
| Active Area: | 345.408 × 259.056 mm |
| Bezel Opening: | 347 × 260.7 mm |
| Outline Dimensions: | 359 × 284.8 × 13.3 mm |
| Power Supply: | 5.0V (Typ.) |
| Operating Temperature: | 0 ~ 50 °C |
| Storage Temperature: | -20 ~ 60 °C |
| Application: | Digital Signage |
| LCD Panel Specs | |
| Diagonal Size | 17-23.9" |
| Resolution | 1280-1919 px (WXGA/HD/SXGA) |
| Interface | LVDS |
| Pin Count | 21-30 |
| Application | Signage & Commercial |
| Panel Technology | a-Si TFT-LCD |
| Display Mode | IPS / ADS / AHVA / FFS |
| Touch Panel | Without touch |
| Brightness | 0-299 nits |
| Backlight | LED |
| Operating Temp | Standard (0 °C) |
