| Model: | AC121SA02 |
| Brand: | Mitsubishi |
| Diagonal Size: | 12.1 inch |
| Resolution: | 800 × 600 (SVGA, 82 PPI) |
| Pixel Format: | RGB Vertical Stripe |
| Panel Type: | a-Si TFT-LCD, LCM |
| Display Mode: | TN, Normally White, Transmissive |
| Brightness: | 500 cd/m² (Typ.) |
| Contrast Ratio: | 800:1 (Typ.) (TM) |
| Viewing Angle: | 80/80/60/80 (Typ.)(CR≥10) (L/R/U/D) |
| Best Viewing Direction: | 6 o'clock |
| Response Time: | 4/12 (Typ.)(Tr/Td) ms |
| Display Colors: | 262K/16.7M 72% NTSC |
| Surface: | Antiglare, Hard coating (3H) |
| Backlight: | WLED, 100K hours, With LED Driver |
| Refresh Rate: | 60 Hz |
| Interface: | LVDS (1 ch, 6/8-bit), 20 pins Connector |
| Touch Panel: | Without |
| Active Area: | 246 × 184.5 mm |
| Bezel Opening: | 249 × 187.5 mm |
| Outline Dimensions: | 260.5 × 203 × 10 mm |
| Weight: | 580 g (Typ.) |
| Power Supply: | 3.3V (Typ.) |
| Operating Temperature: | -30 ~ 80 °C |
| Storage Temperature: | -30 ~ 80 °C |
| Application: | Industrial |
| LCD Panel Specs | |
| Diagonal Size | 10-12.9" |
| Resolution | 800-1279 px (WVGA/SVGA/XGA) |
| Interface | LVDS |
| Pin Count | 1-20 |
| Application | Industrial |
| Panel Technology | a-Si TFT-LCD |
| Display Mode | TN |
| Touch Panel | Without touch |
| Brightness | 500-699 nits |
| Backlight | LED |
| Operating Temp | Wide (-30 °C) |
