BOE ZS070FHM-L30 LCD

Specification

Model P/N:ZS070FHM-L30
Brand:BOE
Diagonal Size:7.0"
Resolution:1080(RGB)×1920, FHD 315PPI
Contrast Ratio:1000 : 1 (Typ.) (TM)
Viewing Angle:80/80/80/80 (Typ.)(CR≥10)
Color Depth:16.7M 80% NTSC
Backlight:WLED , No Driver
Signal Type:MIPI (4 data lanes) , 40 pins Connector
Panel Type:LTPS TFT-LCD, LCM
Pixel Format:RGB Vertical Stripe
Active Area:86.832(W)×154.368(H) mm
Bezel Opening:-
Treatment:Hard coating
Luminance:450 cd/m² (Typ.)
Outline(mm):89.33 × 160.07 (H×V×D)
Response:9 (Max.)(Tr+Td) ms
Good View at:Symmetry
Work Mode:ADS, Normally Black, Transmissive
Mass:TBD
Used for:VOIP Phone
Refresh Rate:120Hz
Touchscreen:In-Cell Touch, I²C
Voltage Supply:1.8/5.8/-5.8V (Typ.)(VDDIO/AVDD/AVEE)
Max Ratings:Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C
