YZ270CD01-DE15 YZGL LCD panel replacement

YZ270CD01-DE15 YZGL LCD panel replacement

Delivery in 5 to 7 days ( ...... ) ( Tax free )

  • 100% tested working
  • 60 days Money back
  • 120 days warranty
  • Contact for Volume pricing
  • Description
  • Reviews (0)

Description




Panel Brand:YZGL
Panel Size:27.0 inch
Resolution:1920(RGB)×1080 , FHD
Display Area:597.888(W)×336.312(H) mm
Outline Size:630(W)×368.4(H)×26.9(D) mm
Brightness:1500 cd/m2 (Typ.)
Viewing Angle:89/89/89/89 (Typ.)(CR≥10)
Best View on:Symmetry
Display Colors:16.7M80%(CIE1931)
Frequency: 60Hz
Weight:3.75/3.85Kgs (Typ./Max.)
Panel Model:YZ270CD01-DE15
Panel Type:a-Si TFT-LCD , LCM
Pixel Format: RGB Vertical Stripe
Bezel Opening:602(W)×340.4(H) mm
Surface:Antiglare, Hard coating (3H)
Contrast Ratio:1000:1 (Typ.) (TM)
Display Mode: Normally Black, Transmissive
Response Time:14 (Typ.)(G to G)
Lamp Type:WLED , 50K hours , With LED Driver
Touch Screen:Without
Application: Outdoor High Brightness, Digital Signage,
Signal Interface: LVDS (2 ch, 8-bit), 30 pins , Connector
Input Voltage: 5.0V (Typ.)
Environment: Operating Temp.: 0 ~ 50 °C ;Storage Temp.: -20 ~ 60 °C
