BOE VS021ZRM-ND0-69P0 LCD

Specification

Model P/N:VS021ZRM-ND0-69P0
Brand:BOE
Diagonal Size:2.1"
Resolution:1200(RGB)×1200 806PPI
Brightness:800 cd/m² (Typ.)
Contrast Ratio:500:1 (Typ.) (TM)
Viewing Angle:85/85/85/85 (Typ.)(CR≥10)
Panel Type:LTPS TFT-LCD, LCM
Pixel Format:RGB Vertical Stripe
Active Area:37.8(W)×37.8(H) mm
Bezel Opening:-
Response Time:8.5 (Max.)(G to G)
Outline Size:41(W)×44.4(H) mm
Surface:Hard coating (1H)
Best View on:Symmetry
Display Colors:16.7M 72% NTSC
Lamp Type:4S2P WLED , Without Driver
Frequency:90Hz
Touch Screen:Without
Panel Weight:-
Application:HMD VR AR
Signal Interface:MIPI (2 ch, 4 data lanes) , 50 pins Connector
Input Voltage:1.8/5.5/-5.5V (Typ.)(VDDI/AVDD/AVEE)
