BOE VS019U0M-NH0-DKP0 LCD

Specification

Model P/N:VS019U0M-NH0-DKP0
Brand:BOE
Diagonal Size:1.9"
Resolution:1600(RGB)×1200, UXGA 1058PPI
Contrast Ratio:550:1 (Typ.) (TM)
Viewing Angle:25/25/35/35 (Typ.)(CR≥100)
Panel Type:LTPS TFT-LCD, LCM
Pixel Format:RGB Vertical Stripe
Active Area:38.4(W)×28.8(H) mm
Bezel Opening:-
Outline Dim:41.2(H)×40.6(V) ×1.82(D) mm
Treatment:Hard coating (3H)
Luminance:1000 cd/m² (Typ.)
View Direction:Symmetry
Response Time:5.5 (Max.)(G to G)
Operating Mode:ADS, Normally Black, Transmissive
Support Color:16.7M 71% NTSC
Light Source:WLED [4S4P] , W/O Driver
Weight:7.0±1.0g
Designed For:HMD VR AR
Frame Rate:120Hz
Touch Panel:Without
Interface Type:MIPI (2 ch, 4 data lanes) , 50 pins Connector
Power Supply:1.8/6.0/-6.0V (Typ.)(VDD/AVDD/AVEE)
