V185BJ1-PE1 Innolux LCD panel replacement for TV Sets

Brand：Innolux
Model：V185BJ1-PE1
Diagonal Size：18.5 inch
Type：a-Si TFT-LCD ， CELL
Pixel Format：1366(RGB)×768[WXGA]
Configuration：RGB Vertical Stripe
Active Area：409.8(H)×230.4(V) mm
Outline Dim.：422.2(H)×285.65(V)×1.287(D) mm
Bezel Area：-
Treatment：Antiglare (Haze 1%)
Luminance：0 cd/m2
Contrast Ratio：3000:1 (Typ.) (TM)
View Direction：Symmetry
Response Time：9.0 (Typ.)(G to G)
Viewing Angle：88/88/88/88 (Typ.)(CR≥20)
Operating Mode：Super MVA， Normally Black， Transmissive
Plate Thickness：0.50+0.50 mm
Transmittance：5.0% (Typ.)(with Polarizer)
Support Color：16.7M
Light Source：No B/L， W/O Driver
Weight： 317±16g
Designed For： TV Sets,
Frame Rate：60Hz
Touch Panel：Without
Interface Type： 30 pinsLVDS (1 ch， 8-bit)， Connector
Power Supply：5.0V (Typ.)
Environment： Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C
