URT UMSH-8272MD-1T LCD

Specification

Model P/N:UMSH-8272MD-1T
Brand:URT
Diagonal Size:7.0"
Resolution:800(RGB)×480, WVGA 133PPI
Contrast Ratio:500:1 (Typ.) (TM)
Viewing Angle:80/80/80/50 (Typ.)(CR≥10)
Panel Type:a-Si TFT-LCD, LCM
Pixel Format:RGB Vertical Stripe
Active Area:152.4(W)×91.44(H) mm
Bezel Opening:-
Outline Dim:165(H)×104(V) ×7(D) mm
Treatment:-
Luminance:240 cd/m² (Typ.)
View Direction:6 o'clock
Response Time:10/15 (Typ.)(Tr/Td
Operating Mode:TN, Normally White, Transmissive
Support Color:262K
Light Source:WLED , 20K hours , With LED Driver
Weight:-
Designed For:Industrial
Frame Rate:60Hz
Touch Panel:4-wire Resistive Touch
Interface Type:Parallel RGB (1 ch, 6-bit) , 40 pins Connector
Power Supply:3.3V (Typ.)
