UG-5664ASYGF01 WiseChip LCD panel replacement for Industrial Application

Panel Brand：Univision
Panel Model： UG-5664ASYGF01
Panel Size：5.5 inch
Panel Type：PM-OLED， OLED
Resolution：256×64
Pixel Format：Rectangle
Display Area：135.65(W)×33.89(H) mm
Bezel Opening：137.65(W)×35.89(H) mm
Outline Size：146(W)×45(H)×2.1(D) mm
Surface：Antiglare
Brightness：60 cd/m2 (Typ.)
Contrast Ratio：10000:1 (Typ.) (TM)
Viewing Angle：-
Display Mode：-
Best View on：Symmetry
Response Time：0.01
Display Colors：Grayscale(Y)
Lamp Type：self， 100K hours
Frequency： –
Touch Screen：Without
Driver IC：COF Built-in SSD1322
Panel Weight： 27.1g (Typ.)
Application： Industrial Application,
Signal Interface： 8-bit 6800/8080 parallel， 3/4-wire SPI， 30 pins ， FPC
Input Voltage：2.8/15V (Typ.)(VCI/VCC)
Environment：Operating Temp.: -40 ~ 70 °C ; Storage Temp.: -40 ~ 85 °C
