JDI TX76D02VM0BAA LCD

Specification

Model P/N:TX76D02VM0BAA
Brand:JDI
Diagonal Size:30.0"
Resolution:2560(RGB)×1616 101PPI
Contrast Ratio:1100 : 1 (Typ.) (TM)
Viewing Angle:85/85/85/85 (Min.)(CR≥50)
Color Depth:1.07B 99% sRGB
Backlight:WLED , With LED Driver
Signal Type:LVDS (4 ch, 10-bit) , Connector 82 pins
Panel Type:a-Si TFT-LCD, LCM
Pixel Format:RGB Vertical Stripe
Active Area:641.28(W)×404.808(H) mm
Bezel Opening:648.3(W)×409.8(H) mm
Treatment:Antiglare, Hard coating (2H)
Luminance:650 cd/m² (Typ.)
Response:10/10 (Typ.)(Tr/Td) ms
Good View at:Symmetry
Work Mode:IPS-Pro, Normally Black, Transmissive
Mass:7.10Kgs (Typ.)
Used for:Medical Imaging
Refresh Rate:60Hz
Touchscreen:Without
Voltage Supply:12.0V (Typ.)
Max Ratings:Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C
Outline (mm):687.3×454.4×38.5 (H×V×D)
