JDI TX54D14VC0CAA LCD

Specification

Model P/N:TX54D14VC0CAA
Brand:JDI
Diagonal Size:21.3"
Resolution:1600(RGB)×1200, UXGA 94PPI
Brightness:820 cd/m² (Typ.)
Contrast Ratio:1100:1 (Typ.) (TM)
Viewing Angle:85/85/85/85 (Typ.)(CR≥10)
Panel Type:a-Si TFT-LCD, LCM
Pixel Format:RGB Vertical Stripe
Active Area:432(W)×324(H) mm
Bezel Opening:-
Response Time:12/10 (Typ.)(Tr/Td)
Outline Size:460.6(W)×362(H) ×28(D) mm
Surface:Antiglare
Best View on:Symmetry
Display Colors:16.7M 99% sRGB
Lamp Type:3 strings WLED , With LED Driver
Frequency:60Hz
Touch Screen:Without
Panel Weight:3.00/3.40Kgs (Typ./Max.)
Application:Medical Imaging
Signal Interface:LVDS (2 ch, 8-bit) , 30 pins Connector
Input Voltage:12.0V (Typ.)
