HITACHI TX38D88VC1GAA LCD

Specification

Model P/N:TX38D88VC1GAA
Brand:HITACHI
Diagonal Size:15.0"
Resolution:1024(RGB)×768, XGA 85PPI
Contrast Ratio:600:1 (Typ.) (TM)
Viewing Angle:80/80/50/50 (Typ.)(CR≥10)
Panel Type:a-Si TFT-LCD, LCM
Pixel Format:RGB Vertical Stripe
Active Area:304.128(W)×228.096(H) mm
Bezel Opening:307.1(W)×231.1(H) mm
Outline Dim:315.8(H)×241.5(V) ×9.7(D) mm
Treatment:Glare (Haze 0%)
Luminance:430 cd/m² (Typ.)
View Direction:6 o'clock
Response Time:30/20 (Typ.)(Tr/Td)
Operating Mode:TN, Normally White, Transmissive
Support Color:262K 50% NTSC
Light Source:CCFL [2 pcs] , 10K hours , W/O Driver
Designed For:Laptop
Frame Rate:60Hz
Touch Panel:Without
Interface Type:LVDS (1 ch, 6-bit) , 30 pins Connector
Power Supply:3.3V (Typ.)
Form Style:Wedge (PCBA Bent, T≥5.2mm)
