TX06D15VM1EAA KOE LCD panel replacement

Brand：HITACHI
Model：TX06D15VM1EAA
Diagonal Size：2.2 inch
Type：a-Si TFT-LCD, LCM
Pixel Format：176(RGB)×220[QCIF+]
Configuration：RGB Vertical Stripe
Active Area：34.848(H)×43.56(V) mm
Outline Dim.：41.85(H)×56(V) mm
Luminance：60 cd/m2 (Typ.)
Contrast Ratio：40:1 (Typ.) (TM) 15:1 (Typ.) (RF)
View Direction：Symmetry
Response Time：35 (Typ.)(Tr+Td)
Viewing Angle：-
Operating Mode：IPS, Normally Black, Transflective
Support Color：65K/262K
Light Source：WLED[1S3P]
Weight： 13.8g (Typ.)
Designed For： Mobile Phone,
Frame Rate：-
Touch Panel：Without
Interface Type： 45 pinsParallel RGB + SPI, FPC
Power Supply：2.8/2.8V (Typ.)(VCC/VCI)
Environment： Operating Temperature: -20 ~ 70 °C ; Storage Temperature: -30 ~ 80 °C
