BOE TV101WUM-NL0 LCD

Specification

Model P/N:TV101WUM-NL0
Brand:BOE
Diagonal Size:10.1"
Resolution:1200(RGB)×1920, WUXGA 225PPI
Brightness:350 cd/m² (Typ.)
Contrast Ratio:1000:1 (Typ.) (TM)
Viewing Angle:85/85/85/85 (Typ.)(CR≥10)
Panel Type:a-Si TFT-LCD, LCM
Pixel Format:RGB Vertical Stripe
Active Area:135.36(W)×216.576(H) mm
Bezel Opening:-
Response Time:30 (Typ.)(Tr+Td)
Outline Size:143(W)×227.926(H) ×4.3(D) mm
Surface:Hard coating
Best View on:Symmetry
Display Colors:16.7M 71% NTSC
Lamp Type:8S4P WLED , 15K hours , Without Driver
Frequency:60Hz
Touch Screen:Without
Panel Weight:125g (Max.)
Application:Pad & Tablet
Signal Interface:MIPI (4 data lanes) , 45 pins Connector
Input Voltage:3.3V (Typ.)
