BOE TV101WUM-LM0 LCD

Specification

Model P/N:TV101WUM-LM0
Brand:BOE
Diagonal Size:10.1"
Resolution:1200(RGB)×1920, WUXGA 225PPI
Contrast Ratio:1400:1 (Typ.) (TM)
Viewing Angle:85/85/85/85 (Typ.)(CR≥10)
Panel Type:a-Si TFT-LCD, Assembly
Pixel Format:RGB Vertical Stripe
Active Area:135.36(W)×216.576(H) mm
Bezel Opening:-
Outline Dim:159.36(H)×240.58(V) ×5.25(D) mm
Treatment:Anti Fingerprint, Hard coating (7H)
Luminance:440 cd/m² (Typ.)
View Direction:Symmetry
Response Time:25 (Typ.)(Tr+Td), 45 (Typ.)(G to G)
Operating Mode:-
Support Color:16.7M 98% sRGB
Light Source:WLED [8S4P] , 30K hours , W/O Driver
Weight:207g (Max.)
Designed For:Pad & Tablet
Frame Rate:60Hz
Touch Panel:In-Cell Touch, I²C
Interface Type:MIPI (4 data lanes) , 51 pins Connector
Power Supply:1.8/6.0/-6.0V (Typ.)(VDDIO/AVDD/AVEE)
