TIANMA TM320240ONFWGWC3 LCD

Specification

Model P/N:TM320240ONFWGWC3
Brand:TIANMA
Diagonal Size:2.5"
Resolution:320(RGB)×240, QVGA 162PPI
Contrast Ratio:350 : 1 (Typ.) (TM)
Viewing Angle:55/55/55/55 (Typ.)(CR≥2)
Color Depth:262K 70% NTSC
Backlight:4S1P WLED , No Driver
Signal Type:Parallel RGB (1 ch, 6-bit) + SPI , FPC 39 pins
Panel Type:a-Si TFT-LCD, LCM
Pixel Format:RGB Vertical Stripe
Active Area:49.92(W)×37.44(H) mm
Bezel Opening:-
Treatment:-
Luminance:150 cd/m² (Typ.)
Response:35 (Typ.)(Tr+Td) ms
Good View at:12 o'clock
Work Mode:TN, Normally White, Transmissive
Mass:TBD
Used for:Handheld & PDA
Refresh Rate:60Hz
Touchscreen:4-wire Resistive Touch
Voltage Supply:2.8/2.8V (VDD/VDDI)
Max Ratings:Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C
Outline (mm):57×46.72×4.1 (H×V×D)
