AVIC TM150TDSG59 LCD

Specification

Model P/N:TM150TDSG59
Brand:AVIC
Diagonal Size:15.0"
Resolution:1024(RGB)×768, XGA 85PPI
Brightness:-
Contrast Ratio:600:1 (Typ.) (TM)
Viewing Angle:80/80/80/80 (Typ.)(CR≥10)
Panel Type:a-Si TFT-LCD, LCM
Pixel Format:RGB Vertical Stripe
Active Area:304.128(W)×228.096(H) mm
Bezel Opening:-
Response Time:3/5 (Typ.)(Tr/Td)
Best View on:6 o'clock
Display Colors:262K/16.7M 60% NTSC
Lamp Type:WLED , 30K hours
Frequency:60Hz
Touch Screen:Without
Panel Weight:-
Application:Industrial
Signal Interface:LVDS (1 ch, 6/8-bit) , 20 pins Connector
Input Voltage:3.3V (Typ.)
