TIANMA TM104TDGP10 LCD

Specification

Model P/N:TM104TDGP10
Brand:TIANMA
Diagonal Size:10.4"
Resolution:1024(RGB)×768, XGA 123PPI
Contrast Ratio:1200:1 (Typ.) (TM)
Viewing Angle:85/85/85/85 (Typ.)(CR≥10)
Panel Type:a-Si TFT-LCD, LCM
Pixel Format:RGB Vertical Stripe
Active Area:210.432(W)×157.824(H) mm
Bezel Opening:213.43(W)×160.82(H) mm
Outline Dim:230(H)×175.8(V) ×9.06(D) mm
Treatment:Antiglare
Luminance:450 cd/m² (Typ.)
View Direction:Symmetry
Response Time:35 (Typ.)(Tr+Td)
Operating Mode:SFT, Normally Black, Transmissive
Support Color:262K/16.7M 50% NTSC
Light Source:WLED [8S4P] , 50K hours , With LED Driver
Weight:430g (Typ.)
Designed For:Industrial
Frame Rate:60Hz
Touch Panel:Without
Interface Type:LVDS (1 ch, 6/8-bit) , 20 pins Connector
Power Supply:3.3V (Typ.)
