TIANMA TM104SDHG30-02 LCD

Specification

Model P/N:TM104SDHG30-02
Brand:TIANMA
Diagonal Size:10.4"
Resolution:800(RGB)×600, SVGA 96PPI
Brightness:350 cd/m² (Typ.)
Contrast Ratio:500:1 (Typ.) (TM)
Viewing Angle:70/70/60/70 (Typ.)(CR≥10)
Panel Type:a-Si TFT-LCD, LCM
Pixel Format:RGB Vertical Stripe
Active Area:211.2(W)×158.4(H) mm
Bezel Opening:214.2(W)×162.5(H) mm
Response Time:25 (Typ.)(Tr+Td)
Outline Size:228.4(W)×175.4(H) ×6.5(D) mm
Surface:Antiglare, Hard coating (3H)
Best View on:6 o'clock
Display Colors:16.7M 50% NTSC
Lamp Type:3S12P WLED , 30K hours , Without Driver
Frequency:60Hz
Touch Screen:Without
Panel Weight:341g
Application:Industrial
Signal Interface:TTL (1 ch, 8-bit) , 60 pins FPC
Input Voltage:3.3/11.0/25.0/-7.0V (Typ.)(VCC/AVDD/VGH/VGL)
