TIANMA TM103XDKP36-00 LCD

Specification

Model P/N:TM103XDKP36-00
Brand:TIANMA
Diagonal Size:10.3"
Resolution:1280(RGB)×480, DVGA 133PPI
Contrast Ratio:1000 : 1 (Typ.) (TM)
Viewing Angle:88/88/88/88 (Typ.)(CR≥10)
Color Depth:16.7M 68% NTSC
Backlight:7S3P WLED , 30K hours , No Driver
Signal Type:LVDS (1 ch, 8-bit) , Connector 30 pins
Panel Type:a-Si TFT-LCD, LCM
Pixel Format:RGB Vertical Stripe
Active Area:243.84(W)×91.44(H) mm
Bezel Opening:-
Treatment:Hard coating, Reflection 5.5% (Typ.)
Luminance:700 cd/m² (Typ.)
Response:25 (Typ.)(Tr+Td) ms
Good View at:Symmetry
Work Mode:SFT, Normally Black, Transmissive
Mass:TBD
Used for:Outdoor High Brightness ，Automotive Display
Refresh Rate:60Hz
Touchscreen:Without
Voltage Supply:3.3V (Typ.)
Max Ratings:Storage Temp.: -40 ~ 85 °C Operating Temp.: -30 ~ 85 °C ; Vibration Level: 3.0G (29.4 m/s²)
Outline (mm):261.04×109.3×11.52 (H×V×D)
