TIANMA TM103XDKP12 LCD

Specification

Model P/N:TM103XDKP12
Brand:TIANMA
Diagonal Size:10.3"
Resolution:1920(RGB)×720 200PPI
Brightness:800 cd/m² (Typ.)
Contrast Ratio:1000:1 (Typ.) (TM)
Viewing Angle:88/88/88/88 (Typ.)(CR≥10)
Panel Type:a-Si TFT-LCD, LCM
Pixel Format:RGB Vertical Stripe
Active Area:243.648(W)×91.368(H) mm
Bezel Opening:-
Response Time:20 (Typ.)(Tr+Td)
Outline Size:262.04(W)×110.3(H) ×8.7(D) mm
Surface:Hard coating, Reflection 5.5% (Typ.)
Best View on:Symmetry
Display Colors:16.7M 74% NTSC
Lamp Type:8S3P WLED , 10K hours , Without Driver
Frequency:60Hz
Touch Screen:Without
Panel Weight:TBD
Application:Outdoor High Brightness ，Automotive Display
Signal Interface:LVDS (2 ch, 8-bit) , 50 pins Connector
Input Voltage:3.3V (Typ.)
