AVIC TM080SDH04 LCD

Specification

Model P/N:TM080SDH04
Brand:AVIC
Diagonal Size:8.0"
Resolution:800(RGB)×600, SVGA 125PPI
Contrast Ratio:500:1 (Typ.) (TM)
Viewing Angle:70/70/50/70 (Typ.)(CR≥10)
Panel Type:a-Si TFT-LCD, LCM
Pixel Format:RGB Vertical Stripe
Active Area:162(W)×121.5(H) mm
Bezel Opening:164.8(W)×124.3(H) mm
Outline Dim:183(H)×141(V) ×5.9(D) mm
Treatment:Antiglare
Luminance:200 cd/m² (Typ.)
View Direction:6 o'clock
Response Time:25 (Typ.)(Tr+Td)
Operating Mode:TN, Normally White, Transmissive
Support Color:262K/16.7M 50% NTSC
Light Source:WLED [3S5P] , 15K hours , W/O Driver
Weight:250g
Designed For:Digital Photo Frame
Frame Rate:60Hz
Touch Panel:Without
Interface Type:Parallel RGB (1 ch, 6/8-bit) , 50 pins FPC
Power Supply:3.3/12.5/22.0/-7.0V (Typ.)(VCC/AVDD/VGH/VGL)
