TIANMA TM060JDZG01 LCD

Specification

Model P/N:TM060JDZG01
Brand:TIANMA
Diagonal Size:6.0"
Resolution:800(RGB)×1280, WXGA 251PPI
Brightness:380 cd/m² (Typ.)
Contrast Ratio:800:1 (Typ.) (TM)
Viewing Angle:85/85/85/85 (Typ.)(CR≥10)
Panel Type:a-Si TFT-LCD, LCM
Pixel Format:RGB Vertical Stripe
Active Area:80.76(W)×129.216(H) mm
Bezel Opening:-
Response Time:25 (Typ.)(Tr+Td)
Outline Size:87.76(W)×140.57(H) ×2.92(D) mm
Surface:Clear, Hard coating (3H)
Best View on:Symmetry
Display Colors:16.7M 68% NTSC
Lamp Type:8S2P WLED , 20K hours , Without Driver
Frequency:60Hz
Touch Screen:Without
Panel Weight:TBD
Application:Handheld & PDA ，VOIP Phone ，Healthcare
Signal Interface:MIPI , 40 pins FPC
Input Voltage:1.8/5.7/-5.7V (Typ.)(VDDI/AVDD/AVEE)
