TIANMA TM057JYHP03 LCD

Specification

Model P/N:TM057JYHP03
Brand:TIANMA
Diagonal Size:5.7"
Resolution:720(RGB)×1280, WXGA 256PPI
Brightness:0 cd/m²
Contrast Ratio:600:1 (Typ.) (TM)
Viewing Angle:80/80/80/80 (Typ.)(CR≥10)
Panel Type:a-Si TFT-LCD, CELL , Full Cell
Pixel Format:RGB Vertical Stripe
Active Area:71.28(W)×126.72(H) mm
Bezel Opening:-
Response Time:25 (Typ.)(Tr+Td)
Outline Size:74.28(W)×134.57(H) ×0.4(D) mm
Surface:Without Polarizer
Best View on:Symmetry
Display Colors:16.7M 70% NTSC
Lamp Type:No B/L
Frequency:-
Touch Screen:Without
Panel Weight:-
Application:Mobile Phone
Driver IC:COGSuggest HX8394-A00, HX8394-A01, HX8394-B, NT35520, NT35521, OTM1283
Glass Depth:-
Transmissivity:4.6% (Typ.)(with Polarizer)
