TIANMA TM050RDH01 LCD

Specification

Model P/N:TM050RDH01
Brand:TIANMA
Diagonal Size:5.0"
Resolution:800(RGB)×480, WVGA 188PPI
Contrast Ratio:600 : 1 (Typ.) (TM)
Viewing Angle:70/70/50/70 (Typ.)(CR≥10)
Color Depth:16.7M 50% NTSC
Backlight:7S2P WLED , 20K hours , No Driver
Signal Type:Parallel RGB (1 ch, 8-bit) , FPC 40 pins
Panel Type:a-Si TFT-LCD, LCM
Pixel Format:RGB Vertical Stripe
Active Area:108(W)×64.8(H) mm
Bezel Opening:111.1(W)×67.9(H) mm
Treatment:Antiglare, Hard coating (3H)
Luminance:250 cd/m² (Typ.)
Response:20 (Typ.)(Tr+Td) ms
Good View at:6 o'clock
Work Mode:TN, Normally White, Transmissive
Mass:TBD
Used for:Portable Navigation ，MID UMPC ，MP3 PMP
Refresh Rate:60Hz
Touchscreen:Without
Voltage Supply:3.3V (Typ.)
Max Ratings:Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C
Outline (mm):120.7×75.8×3.1 (H×V×D)
