TIANMA TM045YDZA26 LCD

Specification

Model P/N:TM045YDZA26
Brand:TIANMA
Diagonal Size:4.5"
Resolution:480(RGB)×854, FWVGA 219PPI
Brightness:350 cd/m² (Typ.)
Contrast Ratio:500:1 (Typ.) (TM)
Viewing Angle:70/50/70/70 (Typ.)(CR≥10)
Panel Type:a-Si TFT-LCD, LCM
Pixel Format:RGB Vertical Stripe
Active Area:55.44(W)×98.637(H) mm
Bezel Opening:-
Response Time:20 (Typ.)(Tr+Td)
Outline Size:60(W)×109(H) ×2.2(D) mm
Surface:-
Best View on:6 o'clock
Display Colors:16.7M 65% NTSC
Lamp Type:6S2P WLED , Without Driver
Frequency:60Hz
Touch Screen:Without
Panel Weight:TBD
Application:Mobile Phone
Signal Interface:MIPI (2 data lanes) , 25 pins FPC
Input Voltage:(1.8/2.8)/2.8V (Typ.)(IOVCC/VCC)
