TIANMA TM028HDZP01 LCD

Specification

Model P/N:TM028HDZP01
Brand:TIANMA
Diagonal Size:2.8"
Resolution:240(RGB)×320, QVGA 141PPI
Brightness:280 cd/m² (Typ.)
Contrast Ratio:800:1 (Typ.) (TM)
Viewing Angle:80/80/80/80 (Typ.)(CR≥10)
Panel Type:a-Si TFT-LCD, LCM
Pixel Format:RGB Vertical Stripe
Active Area:43.2(W)×57.6(H) mm
Bezel Opening:44.2(W)×58.6(H) mm
Response Time:25/35 (Typ./Max.)(Tr+Td)
Outline Size:48.4(W)×69.2(H) ×3.1(D) mm
Surface:Hard coating
Best View on:Symmetry
Display Colors:65K/262K 70% NTSC
Lamp Type:1S4P WLED , 30K hours
Frequency:60Hz
Touch Screen:Without
Panel Weight:-
Application:Handheld & PDA
Signal Interface:CPU/SPI , 40 pins FPC
Input Voltage:3.3 /3.3V (Typ.)(VCC/IOVCC)
