TIANMA TM028HDZG59 LCD

Specification

Model P/N:TM028HDZG59
Brand:TIANMA
Diagonal Size:2.8"
Resolution:240(RGB)×320, QVGA 141PPI
Contrast Ratio:400 : 1 (Typ.) (TM)
Viewing Angle:70/70/70/58 (Typ.)(CR≥10)
Color Depth:65K/262K 63% NTSC
Backlight:1S4P WLED , No Driver
Signal Type:16-bit 8080 parallel , FPC 37 pins
Panel Type:a-Si TFT-LCD, LCM
Pixel Format:RGB Vertical Stripe
Active Area:43.2(W)×57.6(H) mm
Bezel Opening:-
Treatment:-
Luminance:300 cd/m² (Typ.)
Response:25 (Typ.)(Tr+Td) ms
Good View at:12 o'clock
Work Mode:TN, Normally White, Transmissive
Mass:TBD
Used for:Mobile Phone
Refresh Rate:-
Touchscreen:Without
Voltage Supply:2.7/3.3V (Min./Max.)(VCI/VCC1/VCC2)
Max Ratings:Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C
Outline (mm):50×69.2×3.3 (H×V×D)
