TIANMA TM028HDZ30 LCD

Specification

Model P/N:TM028HDZ30
Brand:TIANMA
Diagonal Size:2.8"
Resolution:240(RGB)×320, QVGA 141PPI
Contrast Ratio:350:1 (Typ.) (TM)
Viewing Angle:70/70/70/60 (Typ.)(CR≥10)
Panel Type:a-Si TFT-LCD, LCM
Pixel Format:RGB Vertical Stripe
Active Area:43.2(W)×57.6(H) mm
Bezel Opening:44.2(W)×58.6(H) mm
Outline Dim:50(H)×69.2(V) ×3.47(D) mm
Treatment:-
Luminance:210 cd/m² (Typ.)
View Direction:12 o'clock
Response Time:20 (Typ.)(Tr+Td)
Operating Mode:TN, Normally White, Transmissive
Support Color:65K/262K 50% NTSC
Light Source:WLED [1S4P] , W/O Driver
Weight:17.4g
Designed For:Mobile Phone
Frame Rate:60Hz
Touch Panel:Without
Interface Type:8/16-bit 8080 parallel
Power Supply:(1.8/2.8)/2.8V (Typ.)(IOVCC/VCC)
