TIANMA TM022GYH01 LCD

Specification

Model P/N:TM022GYH01
Brand:TIANMA
Diagonal Size:2.2"
Resolution:176(RGB)×220, QCIF+ 128PPI
Contrast Ratio:350:1 (Typ.) (TM)
Viewing Angle:45/45/40/20 (Typ.)(CR≥10)
Panel Type:a-Si TFT-LCD, CELL , Full Cell
Pixel Format:RGB Vertical Stripe
Active Area:34.848(W)×43.56(H) mm
Bezel Opening:-
Outline Dim:38.9(H)×51.6(V) ×1(D) mm
Treatment:Without Polarizer
Luminance:0 cd/m²
View Direction:12 o'clock
Response Time:25 (Typ.)(Tr+Td)
Operating Mode:TN, Normally White, Transmissive
Support Color:262K 60% NTSC
Light Source:No B/L , W/O Driver
Weight:4.00g
Designed For:Mobile Phone
Frame Rate:-
Touch Panel:Without
Interface Type:CPU
Plate Thickness:0.50+0.50 mm
Transmittance:6.9% (Typ.)(with Polarizer)
D-IC Detail:COG Suggest S6D0164, NT39115, ILI9225, HX8340, SPFD5406B
