TIANMA TM018FDH02-00 LCD

Specification

Model P/N:TM018FDH02-00
Brand:TIANMA
Diagonal Size:1.8"
Resolution:128(RGB)×160 114PPI
Brightness:200 cd/m² (Typ.)
Contrast Ratio:350:1 (Typ.) (TM)
Viewing Angle:45/45/50/20 (Typ.)(CR≥10)
Panel Type:a-Si TFT-LCD, LCM
Pixel Format:RGB Vertical Stripe
Active Area:28.416(W)×35.52(H) mm
Bezel Opening:-
Response Time:12 (Typ.)(Tr+Td)
Outline Size:34(W)×47.25(H) ×2.65(D) mm
Surface:Clear, Hard coating (3H)
Best View on:12 o'clock
Display Colors:65K/262K 50% NTSC
Lamp Type:1S2P WLED , 20K hours , Without Driver
Frequency:-
Touch Screen:Without
Panel Weight:-
Application:Mobile Phone
Signal Interface:CPU , 20 pins FPC
Input Voltage:1.8V (Typ.)(VDD)
