TIANMA TL140BDXP02-00 LCD

Specification

Model P/N:TL140BDXP02-00
Brand:TIANMA
Diagonal Size:14.0"
Resolution:2560(RGB)×1440 210PPI
Contrast Ratio:1000 : 1 (Typ.) (TM)
Viewing Angle:88/88/88/88 (Typ.)(CR≥10)
Color Depth:16.7M
Backlight:WLED , With LED Driver
Signal Type:eDP (4 Lanes) , eDP1.3 , Connector 40 pins
Panel Type:LTPS TFT-LCD, LCM
Pixel Format:RGB Vertical Stripe
Active Area:309.27(W)×173.97(H) mm
Bezel Opening:-
Luminance:-
Response:-
Good View at:Symmetry
Work Mode:SFT, Normally Black, Transmissive
Used for:Laptop
Refresh Rate:165Hz
Touchscreen:Without
Voltage Supply:3.3V (Typ.)
Max Ratings:Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C
Outline Shape:Slim (PCBA Flat, T≤3.2mm)
