Kyocera THG062HV1AC-G00 LCD

Specification

Model P/N:THG062HV1AC-G00
Brand:Kyocera
Diagonal Size:6.2"
Resolution:640(RGB)×240, HVGA 109PPI
Brightness:50 cd/m² (Typ.)
Contrast Ratio:40:1 (Typ.) (TM) 35:1 (Typ.) (RF)
Viewing Angle:60/70/40/40 (Typ.)(CR≥5)
Panel Type:a-Si TFT-LCD, LCM
Pixel Format:RGB Vertical Stripe
Active Area:147.84(W)×55.44(H) mm
Bezel Opening:152.4(W)×60.0(H) mm
Response Time:10/10 (Typ.)(Tr/Td)
Outline Size:174.2(W)×73.4(H) ×12.7(D) mm
Surface:Glare (Haze 0%)
Best View on:-
Display Colors:262K 14% NTSC
Lamp Type:1 pcs CCFL , 54K hours , Without Driver
Frequency:60Hz
Touch Screen:Without
Panel Weight:165g
Application:Industrial
Signal Interface:Parallel RGB (1 ch, 6-bit) , 33 pins Connector
Input Voltage:3.3V (Typ.)
