Kyocera THG057VGLAS-H500 LCD

Specification

Model P/N:THG057VGLAS-H500
Brand:Kyocera
Diagonal Size:5.7"
Resolution:640(RGB)×480, VGA 141PPI
Brightness:400 cd/m² (Typ.)
Contrast Ratio:150:1 (Typ.) (TM) 20:1 (Typ.) (RF)
Viewing Angle:80/80/45/80 (Typ.)(CR≥10)
Panel Type:a-Si TFT-LCD, LCM
Pixel Format:RGB Vertical Stripe
Active Area:115.2(W)×86.4(H) mm
Bezel Opening:119.8(W)×91.0(H) mm
Response Time:10/20 (Typ.)(Tr/Td)
Outline Size:144(W)×104.8(H) ×13.5(D) mm
Surface:Glare (Haze 0%), Antireflection
Best View on:6 o'clock
Display Colors:262K 38% NTSC
Lamp Type:2 strings WLED , 50K hours , Without Driver
Frequency:-
Touch Screen:Without
Panel Weight:220g (Typ.)
Application:Industrial
Signal Interface:Parallel RGB (1 ch, 6-bit) , 33 pins Connector
Input Voltage:3.3V (Typ.)
