TRULY TFT3P3546-E LCD

Specification

Model P/N:TFT3P3546-E
Brand:TRULY
Diagonal Size:2.5"
Resolution:240(RGB)×240 97PPI
Contrast Ratio:500:1 (Typ.) (TM)
Viewing Angle:80/80/65/80 (Typ.)(CR≥10)
Panel Type:a-Si TFT-LCD, LCM
Pixel Format:RGB Vertical Stripe
Active Area:62.64(W)×62.64(H) mm
Bezel Opening:67.39(W)×67.39(H) mm
Outline Dim:75.2(H)×87.2(V) mm
Treatment:-
Luminance:650 cd/m² (Typ.)
View Direction:6 o'clock
Response Time:25 (Typ.)(Tr+Td)
Operating Mode:TN, Normally White
Support Color:262K 65% NTSC
Light Source:WLED [4S1P] , W/O Driver
Weight:-
Designed For:Round Display ，Automotive Electronics
Frame Rate:-
Touch Panel:Without
Interface Type:CPU/SPI , 40 pins FPC
Power Supply:3.3V (Typ.)
