TRULY TFT3P2698-E LCD

Specification

Model P/N:TFT3P2698-E
Brand:TRULY
Diagonal Size:7.0"
Resolution:800(RGB)×480, WVGA 134PPI
Contrast Ratio:1000:1 (Min.) (TM)
Viewing Angle:80/80/80/80 (Typ.)(CR≥10)
Panel Type:a-Si TFT-LCD, LCM
Pixel Format:RGB Vertical Stripe
Active Area:154.08(W)×85.92(H) mm
Bezel Opening:156.7(W)×89.1(H) mm
Outline Dim:164.9(H)×100(V) ×6(D) mm
Treatment:-
Luminance:280 cd/m² (Typ.)
View Direction:12 o'clock
Response Time:25 (Typ.)(Tr+Td)
Operating Mode:TN, Normally White, Transmissive
Support Color:16.7M 50% NTSC
Light Source:WLED [3S8P] , W/O Driver
Weight:TBD
Designed For:Automotive Display
Frame Rate:60Hz
Touch Panel:Without
Interface Type:Parallel RGB (1 ch, 8-bit) , 50 pins FPC
Power Supply:3.3/3.3/9.6/18.0/-6.0V (Typ.)(DVDD/IOVCC/VCI/VGH/VGL)
