TRULY TFT1P5357-E LCD

Specification

Model P/N:TFT1P5357-E
Brand:TRULY
Diagonal Size:2.6"
Resolution:240(RGB)×320, QVGA 153PPI
Contrast Ratio:950 : 1 (Typ.) (TM)
Viewing Angle:80/80/80/80 (Typ.)(CR≥10)
Color Depth:262K
Backlight:1S4P WLED , No Driver
Signal Type:CPU , FPC 37 pins
Panel Type:a-Si TFT-LCD, LCM
Pixel Format:RGB Vertical Stripe
Active Area:39.6(W)×52.8(H) mm
Bezel Opening:41.16(W)×54.8(H) mm
Treatment:-
Luminance:230 cd/m² (Typ.)
Response:16 (Typ.)(Tr+Td) ms
Good View at:-
Work Mode:TN, Normally White, Transmissive
Mass:-
Used for:Mobile Phone
Refresh Rate:60Hz
Touchscreen:Without
Voltage Supply:(1.8/2.8)/2.8V (Typ.)(IOVCC/VCC)
Max Ratings:Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C
Outline (mm):46×64×2.2 (H×V×D)
